IK Multimedia

iRig Stomp I/O Pedalboard Controller

SKU: # 689033   |   Model: # IRIG STOMP I/O   |    Product Reviews2 Reviews  Write a Review

iRig Stomp I/O Pedalboard Controller

Additional Photos:

iRig Stomp I/O Pedalboard Controller
iRig Stomp I/O Pedalboard Controller
iRig Stomp I/O Pedalboard Controller

Product Videos :

YouTube Video L&M @ NAMM 2018: IK Multimedia iRig Stomp I/O

Buy Online

iRig Stomp I/O, an all-new generation of USB pedalboard controller for live and studio use, features a built-in audio interface. iRig Stomp I/O is a sturdy, portable pedalboard controller that has 4 built-in switches along with an expression pedal and features a professional high-definition audio interface with 24-bit audio and up to 96kHz sampling rate, a combo input jack for line, instrument or mic input with phantom power, balanced stereo output and high quality 1/4" headphone output ideal for use with the latest Apple devices like the iPhone X.

With its combination 1/4" XLR input, iRig Stomp I/O lets you easily record with a guitar, bass, synth, keyboard or microphone - including studio condenser mics requiring 48V phantom power using its 96kHz/24-bit audio interface on iPhone/iPad, Mac and PC. It has a Class A preamp with gain control and an output level control with VU metering for both input and output levels. The integrated 1/4" headphone output allows for monitoring the signal during tracking or when practicing, while the balanced stereo output can be used to send the signal to an amplifier, a mixer, a PA or powered speakers.

iRig Stomp I/O is designed to give electric and acoustic guitarists, bass players, vocalists, and songwriters a new way to have full control over their tone in any situation. Furthermore, iRig Stomp I/O offers the unique advantage of getting the same sound on stage as in the studio with a solution that is easily updatable as new software and features are released, making it a future-proof system.

iRig Stomp I/O Specifications
• 4 x Metal foot switch with two-colour status LED
• Conversion: 24-bit A/D, 24-bit D/A
• Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz
• Power: USB bus powered (when used with a computer) or DC IN
• Device Connection: USB B-Type and Mini-DIN
• Enclosure: metal sheet

Microphone Input
• Connector: balanced female 3-pin XLR
• Microphone Input Impedance: 3.2 kOhms
• Gain Range: 46 dB
• Phantom Power: +48V 4V
• Frequency Response: 20 Hz 20kHz +/-1.5dB
• Input Noise: -100 dB RMS

Instrument Input
• Frequency response: 20 Hz 20kHz +/-1.5dB
• Input Noise: -100 dB RMS

Stereo Headphone Output
• Connector: 1/4" TRS Jack. Tip: right / Ring: left / Shield: ground
• Headphone Level control: potentiometer
• Headphone Output Power: 100mW into 50Ohms

Stereo Line Output
• Connector: 2x balanced female 1/4" TRS Jack. Tip: hot / Ring: cold / Shield: ground
• Maximum Output Level: +13 dBu into 600 Ohms balanced load
• Frequency Response: from 10 Hz to 21 kHz (+/- 0.2dB)
• Output Dynamic Range: 102 dB(A)
• Output Impedance: 150 Ohms balanced
• Floating Balanced Outputs

MIDI Input/Output
• Connector: 2x 5-pin DIN

Connections and Controls
• Neutrik Combo socket for MIC input and Instrument input (auto selecting)
• +48V phantom power switch
• 1/4" headphones output
• 2 x 1/4" TRS Balanced floating line outputs
• MIDI I/O 5-pin DIN connectors
• 2 x 1/4" TRS External controllers sockets
• B-Type USB socket for connecting a computer (Mac/PC)
• Mini-DIN "iOS" connector for connecting an iOS device
• Barrel DC-in socket for powering up the Stomp I/O and charging the iOS device at the same time

Package includes
• iRig Stomp I/O
• Lightning to Mini-DIN connection cable (60cm/23.62")
• USB A-Type to USB B-Type connection cable (2.5m/8.2ft)
• DC power supply

Dimensions
• Size: 41.5cm / 16.3" x 21cm / 8.5" x 7.2cm / 2.83"
• Weight: 3.2kg / 7.1lb

Device Compatibility
• iOS: Compatible with iPhone 8 Plus, iPhone 8, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPod touch 6th generation, iPod touch 5th generation, iPad Pro (10.5-inch), iPad Pro (12.9-inch) 2nd generation, iPad Pro (12.9-inch) 1st generation, iPad Pro (9.7-inch), iPad mini 4, iPad Air 2, iPad mini 3, iPad Air, iPad mini 2, iPad mini, iPad 5th generation, iPad 4th generation. iOS 6 or later is required.
• Mac: macOS 10.6 or later. One free USB port.
• Windows: Fully supports Windows 10 WASAPI for low latency audio. One free USB port. (ASIO4ALL is required on Windows 7 and 8 for low latency audio)

Media


L&M @ NAMM 2018: IK Multimedia iRig Stomp I/OWatch Video
Youtube video product demo
