Audinate Dante AVIO 2-Channel Output Adapter

Dante AVIO Adapters let you use your favourite legacy audio gear with any Dante-connected system, delivering the interoperability, performance and scalability that only networking can bring. Cost effective, compact and built for the road, Dante AVIO adapters bring the modern connectivity that every audio pro needs in their toolbox.

Dante AVIO Analog Outputs let you drive analog line-level products you already own from any Dante-connected system. Bring your amplifiers, powered speakers and more to the world of audio networking with Dante AVIO. Available in 1- and 2-channel versions.

• Send audio to analog power amplifiers and powered speakers over a Dante audio network


• Patch DSPs, analog compressors and equalizers into a Dante system using a combination of Dante AVIO Input and Output adapters


• Create easy drop-points for connecting overflow areas to a Dante network

Specs

Max signal level (balanced): +18dBu / +4dBu / 0dBu; 0dBV /-10dBV
Frequency Response: 20Hz to 20kHz (-/+0.5dB)
Impedance: 150 Ohm balanced; 75 Ohm unbalanced
Dynamic Range: > 100dB
Signal to Noise Ratio: > 100dB
Total Harmonic Distortion: < 0.01% at +4dBu
Connectors: RJ45, 1 XLR-M, 1 XLR-F
Power: Class 1 802.3af PoE
Sample Rates: 44.1, 48, 96 kHz
Network Transport: Dante Audio over IP, AES67 RTP

*Note: 2-channel adapter is illustrated.
