ATOM Producer Lab Complete Production Bundle
Additional Photos:
Product Videos :
YouTube Video
YouTube Video
This product is no longer available.
ATOM Producer Lab: Complete Production Kit
Produce your tracks and get professional results with this tightly integrated, all-PreSonus production kit. Start triggering samples and loops in real-time with the flexible and intuitive ATOM Pad MIDI Controller. Record vocals and create your own sample library with the bus-powered AudioBox USB 96 Audio/MIDI interface and M7 large-diaphragm condenser microphone. Capture and mix it all in Studio One Artist with the bonus MVP Loop content library and the Studio Magic Plug-in Suite for professional results. Everything you need to start making your own music.ATOM: Fast, Flexible Control
Produce beats, play virtual instruments, and trigger sound effects and loops with unsurpassed expressiveness and flexibility! The most versatile pad controller in its class, PreSonus' ATOM pad controller is compatible with most music software and integrates with included Studio One Artist production software to let you create and perform with ease. Perform and produce with virtual instruments and trigger samples and loops in real-time, using 16 full-size, velocity- and pressure-sensitive RGB pads and 8 assignable pad banks. MIDI Keyboard mode, Note Repeat mode, and Full Velocity mode enable you to custom control your instruments. And with 4 programmable rotary encoders and 20 assignable buttons, you can navigate and set more parameters faster.
M7 Condenser Microphone: Capture Every Nuance
Get your mic collection off to a good start with the M7 large-diaphragm condenser microphone. Condenser mics are the overwhelming choice of recording studio professionals, enabling you to capture musical details, harmonics, and subtle nuances that would get lost with dynamic mics. Large-diaphragm condenser microphones like the M7 tend to "warm up" a sound, making them go-to microphones for recording vocals and a wide range of instruments.
AudioBox USB 96: Simple, Reliable, and Portable
The simple, handy AudioBox USB 96 audio/MIDI interface has just the right features for your recording needs, including two combo mic/instrument inputs and zero-latency monitoring, so you can simply plug in and start recording right away. Bus-powered, built to travel, compatible with most recording software for Mac and Windows, and equipped with high-performance microphone preamplifiers and professional-quality, 24-bit, 96 kHz converters, the AudioBox USB 96 makes high-definition recording easy.
Studio One Artist: Make Recording a Breeze
No other recording and production software is as easy to learn and use, yet is capable of creating studio-quality content. Studio One Artist lets you work quickly and stay focused on your inspiration and offers unlimited tracks and plug-ins. Access powerful editing tools without wading through menus. Load and save audio clips, MIDI files, and effects by drag-and-drop. Studio One makes it easy! Best of all, ATOM and Studio One integrate tightly so you can enjoy a blazingly fast, professional-style workflow.
Bonus: Studio Magic Plug-in Suite
This suite of plug-ins adds a wealth of fresh virtual instruments and effects to Studio One. Cherry-picked from the first names in virtual instruments and effects, each plug-in brings a different flavor of practical magic to your songs. These plug-ins aren't gimmicky one-trick ponies - these are real-deal workhorses that you'll rely on for countless mixes.
Features
ATOM Production and Performance Pad Controller
• 16 full-size velocity- and pressure-sensitive, RGB LED pads
• 20 assignable buttons
• 8 assignable pad banks
• Pressure switchable between MIDI aftertouch, channel pressure, and CC messages
• Selectable pad velocity curves and pad pressure thresholds
• MIDI "keyboard" mode, Note Repeat mode, and Full Velocity mode (only send velocity 127)
• Includes MVP Loops content custom-designed for ATOM
• Compatible with most music production and performance software
M7 Condenser Microphone
• Large-diaphragm design
• Captures far more detail than a dynamic mic
• Phantom-powered via AudioBox 96 USB
• Includes mic stand adapter, 9' (3m) XLR Cable and soft carry bag
AudioBox USB 96 2x2 USB 2.0 Recording System
• Bus-powered USB 2.0 audio and MIDI interface
• 24-bit resolution; 44.1, 48, 88.2, and 96 kHz sampling rates
• 2 combo mic/instrument inputs with Class A mic preamplifiers
• 48V phantom power (for included M7 microphone or other condenser microphones)
• Zero-latency monitoring via internal analog mixer
• 1/3U rack-mountable
• USB cable included for connection to computer
Studio One Artist Production Software
• Streamlined, easy to use and navigate interface
• Unlimited audio tracks, MIDI tracks, virtual instruments, buses, and FX channels
• Content browser with convenient sort options and preview player
• Real-time audio time-stretching and resampling
• Transient detection and editing and groove extraction
• Automatic delay compensation
• Instantly configures to PreSonus controllers and interfaces, including AudioBox USB 96
• 35 Native Effects 32-bit effects and virtual instrument plug-ins
• 10+ GB of third-party software, loops, and instruments
• Includes Studio Magic Plug-in Suite and MVP Loops Library
• Mac and Windows compatible
Bundle Includes
• ATOM MIDI Pad Controller
• M7 Condenser Microphone with mic stand adapter and 9' (3m) XLR Cable
• AudioBox USB 96 2x2 USB Recording System
• Studio One Artist Production Software
• Studio Magic Plug-in Suite AND MVP Loops Library
Specifications
ATOM
Connection Type: USB 2.0 (bus-powered)
• 16 full-size velocity- and pressure-sensitive, RGB LED pads
• 20 assignable buttons
• 4 endless rotary knobs
• 1 Setup button
Dimensions: 7.95" x 7.68" x 0.82" (202mm x 195mm x 20.75mm)
Weight: 1 lb (0.45 kg)
M7 Microphone
Type: Large-diaphragm condenser microphone
Element: Electret
Polar Pattern: Cardioid
Frequency Response: 40 Hz - 18 kHz
Sensitivity: -39 dBV/pa (12.2 mV/pa)
Rated Impedance: 200Ω
Equivalent Input Noise (EIN): 20 dB
Maximum SPL: 136 dB SPL
Phantom Power Required: +12 to +52 VDC, 3 mA
S/N Ratio: 74 dB
Dynamic Range: 11 dB
Current Consumption: 3.5 mA
Dimensions: 6.69" (Length) x 2.13" (Diameter) (170mm x 54mm)
Weight: 11.3 oz. (320g)
AudioBox USB 96
Microphone Preamp
Type: XLR Female Balanced
Frequency Response (+/-3.0 dB): 20 Hz to 20 kHz
Input Impedance (Balanced): 1200Ω
THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain): < 0.008%
S/N Ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz): > 95 dB
Common Mode Rejection Ratio (1 kHz, 55 dB Gain): > 45 dB
Gain Control Range (+/-1 dB): 0 dB to 35 dB
Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N): -3 dBu
Phantom Power (+/-2 VDC): +48 VDC
Instrument Input
Type: 1/4" TS Female Unbalanced
Input Impedance: 0.5 MΩ
Line Outputs
Type: 1/4" Balanced
Output Impedance: 51Ω
Headphone Output
Type: 1/4" TRS Active Stereo
Maximum Output: 60 mW/Ch @ 60Ω Load
Frequency Response (+/-1.0 dB): 20 Hz - 30 kHz
MIDI I/O: Dual 5-pin Female DIN
Digital Audio
ADC+DAC Dynamic Range (A-wtd, 48 kHz Sample Rate): 105 dB
Bit Depth: 24
Reference Level for 0 dBFS: +4 dBu
Power: USB 2.0 bus-powered
System Requirements
• 4 GB RAM (8 GB or more recommended)
• USB 2.0 port
• Internet connection (needed for software installation and activation)
• Monitor with 1366 x 768 resolution (high-dpi monitor recommended)
• 40 GB hard-drive space
• Universal Control 2.9 or later (for firmware updates)
• Studio One 4.1+ required for native integration
Mac
• Mac® OS X 10.11 or higher (64-bit only)
• Intel® Core® 2 Duo processor (Intel Core i3 or better recommended)
Windows
• Windows® 7 (SP1 + platform update), Windows 8.1, or Windows 10 (64-bit only)
• Intel Core Duo or AMD® Athlon™ X2 processor (Intel Core 2 Duo or AMD Athlon X4 or better recommended)
