Turbosound iNSPIRE iP82 2-Way 8'' Full Range Loudspeaker
Additional Photos:
This product is no longer available.
2 Way 8" Full Range Loudspeaker for Portable PA Applications
The iP82 loudspeaker features an 8" low frequency driver with a low mass voice coil for improved transient response, and a high temperature dome 1" compression driver mounted on a low distortion 70 degree horizontal by 70 degree vertical dispersion waveguide. All drivers are matched with an internal passive crossover network in a reflex-loaded enclosure, which ensures truly professional results. The 2-way full range iP82 is a passive 600-Watt 8" loudspeaker system ideally suited for a wide range of portable speech and music sound reinforcement applications.
The iP82 provides optimal performance as a FOH satellite speaker when used with the Turbosound iP12B and iP15B active subwoofers. The versatile iP82 is also an exceptional choice for sidefill, stage lip, balcony and delay line applications - and is perfect for small to medium-sized performance venues, such as house of worship, boardroom, nightclubs, and much more.
Portable iNSPIRE iP82 Features
• 2 way full range loudspeaker for portable PA applications
• 150 Watts continuous, 600 Watts peak power
• Satellite speaker for use with iP subwoofers
• 8" low frequency driver with low mass voice coil for improved transient response
• High tempurature dome 1" compression driver
• Low distortion waveguide provides 70 deg H x 70 deg V dispersion
• 15 mm (5/8") birch plywood enclosure with hard wearing semi matt black paint finish
• Rugged powder coated perforated steel mesh grille
• Integral 35 mm pole mount and handle
• Neutrik speakON• NL4 connector for reliable long life operation
Technical Specifications
System
Frequency Response: 70 Hz - 18 Hz +/-3 dB
58 Hz - 20 Hz -10 dB
Nominal Dispersion: 70 deg H x 70 deg V @ -6 dB points
Power handling (IEC): 150 W continuous, 600 W peak
Sensitivity: 91 dB (1 W @ 1 m)
Maximum SPL: 113 dB continuous, 119 dB peak
Impedance: 4 Ω
Components: 1 x 8" (203 mm) LF drive; 1 x 1" (25 mm) HF compression driver
Enclosure
Connectors: 1 x Neutrik speakON• NL4
Wiring: Pins 1+ / 1- input, pins 2+ / 2- N/C
Dimensions (H x W x D): 455 x 280 x 235 mm (17.9 x 11.0 x 9.3")
Net weight: 9.3 kg (20.5 lbs)
Construction: 15 mm (5/8") birch plywood sub
Finish: Semi matt black paint
Grille: Powder coated perforated steel
The iP82 loudspeaker features an 8" low frequency driver with a low mass voice coil for improved transient response, and a high temperature dome 1" compression driver mounted on a low distortion 70 degree horizontal by 70 degree vertical dispersion waveguide. All drivers are matched with an internal passive crossover network in a reflex-loaded enclosure, which ensures truly professional results. The 2-way full range iP82 is a passive 600-Watt 8" loudspeaker system ideally suited for a wide range of portable speech and music sound reinforcement applications.
The iP82 provides optimal performance as a FOH satellite speaker when used with the Turbosound iP12B and iP15B active subwoofers. The versatile iP82 is also an exceptional choice for sidefill, stage lip, balcony and delay line applications - and is perfect for small to medium-sized performance venues, such as house of worship, boardroom, nightclubs, and much more.
Portable iNSPIRE iP82 Features
• 2 way full range loudspeaker for portable PA applications
• 150 Watts continuous, 600 Watts peak power
• Satellite speaker for use with iP subwoofers
• 8" low frequency driver with low mass voice coil for improved transient response
• High tempurature dome 1" compression driver
• Low distortion waveguide provides 70 deg H x 70 deg V dispersion
• 15 mm (5/8") birch plywood enclosure with hard wearing semi matt black paint finish
• Rugged powder coated perforated steel mesh grille
• Integral 35 mm pole mount and handle
• Neutrik speakON• NL4 connector for reliable long life operation
Technical Specifications
System
Frequency Response: 70 Hz - 18 Hz +/-3 dB
58 Hz - 20 Hz -10 dB
Nominal Dispersion: 70 deg H x 70 deg V @ -6 dB points
Power handling (IEC): 150 W continuous, 600 W peak
Sensitivity: 91 dB (1 W @ 1 m)
Maximum SPL: 113 dB continuous, 119 dB peak
Impedance: 4 Ω
Components: 1 x 8" (203 mm) LF drive; 1 x 1" (25 mm) HF compression driver
Enclosure
Connectors: 1 x Neutrik speakON• NL4
Wiring: Pins 1+ / 1- input, pins 2+ / 2- N/C
Dimensions (H x W x D): 455 x 280 x 235 mm (17.9 x 11.0 x 9.3")
Net weight: 9.3 kg (20.5 lbs)
Construction: 15 mm (5/8") birch plywood sub
Finish: Semi matt black paint
Grille: Powder coated perforated steel
