Yorkville Sound Elite Series Passive Speaker - 10 inch Woofer - 325 Watts

Departments > Pro Audio & Recording > PA Speaker Cabinets > Speakers - Full Range-Passive > Yorkville Sound > Elite Series Passive Speaker - 10 inch Woofer - 325 Watts
Add to Wish List
SKU: # 161561
Model: #

E10

Your Price: $549.00 CDN

Limited stock available in select stores only Available in store used 2 from $329.00

The two-way E10 loudspeaker is one of the first in a new series of lite cabinets designed and built for maximum versatility in multiple applications. One of the best sounding ultra-compact cabinets in the market, the E10 is a new concept in loudspeaker cabinet design.

Ideal for any small PA rental house, installer or sound company, these loudspeakers may replace a number of specific application cabinets in any inventory.

The E10 is loaded with 100 x 25 ABS Waveguide horn assembly. A modified trapezoidal shape and recessed input jack panel and handle means the E10 cabinet can function perfectly as a wedge monitor or front-of-house loudspeaker. Unlike some 'multi-function' loudspeakers currently in the marketplace, great care has been taken in the design process to ensure that lite cabinets will perform without compromising functionality as either a monitor or a front-of-house enclosure. Neither application was considered as an afterthought.

Integrated stand mount adapters and flyware means the E10 can be utilized in any permanent install or touring application. In addition, the modified cabinet shape means the lite E10 can be installed much closer to vertical surfaces and in some cases, under balconies in tight locations, and can be arrayed in a much tighter less obtrusive cluster.

When used with the EP10 processor, the E10 can be easily used with any lite series subwoofer.

Features:
• 650 Watt Full Range Loudspeaker (325 Watts Program)
• 10-inch Woofer / 1-inch Compression Driver
• Max SPL 128dB Peak (125dB Continuous)
• Designed for Front-of-House or Monitor Applications
• 100 x 25 ABS Waveguide Horn
• Innovative CTL High Frequency Driver Protection
• 2 x Speakon and 2 x 1/4-inch Parallel Inputs
• Integrated All Metal Speaker Standmount Adaptor
• Solid 5/8-inch (15mm) Birch Plywood Construction
• Made in Canada

Specifications:
• System Type: Two Way
• Active or Passive: Passive
• Program Power (Watts): 325 Watts (650 Watts Peak / 250 Watts Continuous)
• Biampable: No
• Nominal Impedance (Ohms): 8
• Sensitivity (dB @1Watt/1m): 100
• Max SPL (dB): 128dB Peak (125dB Continuous)
• Frequency Response (Hz +/- 3dB): 65 - 18k
• Crossover Frequency (Hz): 2900
• Driver Configuration: 10-inch / 1-inch
• HF Driver(s): 1-inch throat (1-inch Titanium Diaphragm)
• HF Horn: ABS Waveguide
• HF Dispersion ( DEG H x DEG V): 100 x 25
• HF Protection: CTL
• LF Driver(s): 10-inch (2-inch voicecoil)
• Inputs - 1/4 IN Jacks: 2
• Inputs - Speakon 4-pin: 2
• Flying Hardware: 3/8 inch x 3 (2 Top / 1 Back)
• Bar Handles: 1
• Pole Mount Adapter (1 3/8 IN -3.5cm): Yes
• Enclosure Materials: 15mm (5/8inch) 11-ply Russian Birch
• Grille: Perforated Metal
• Covering / Finish: Black Ozite (Carpet)
• Optional Covering / Finishes: Black Ultrathane Paint (E10B)
• Processor (optional): EP10 / EP1
• Dimensions (DWH xbackW COM inches): 12 x 13 x 18.5 x 5.5
• Dimensions (DWH xbackW COM cm): 30 x 33 x 45 x 14
• Weight (lbs/kg): 28.2 / 12.8

http://yorkville.com/loudspeakers/elite/product/e10/

Great little speakers!!!1 of 1 customers found this review helpful

FeaturesProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
QualityProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
ValueProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
OverallProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
Product ExperienceI own it
Closest StorePickering, Ontario
Best paired with Ls200p for small to mid size crowd. Love the sound and get compliments each time we do a gig! A must for mobile Dj with small vehicle!
Posted by anonymous on Jan 3, 2016
Was this review helpful?    flag review

The David to Goliath speaker1 of 1 customers found this review helpful

FeaturesProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
QualityProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
ValueProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
OverallProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
Product ExperienceI own it
Closest StoreBurlington, Ontario
I used to always use large 15 inch or bigger speaker cabinets until recently. The E10 has made a big impression on me for quality of sound and SPL output. I love the small cabinet and power to weight ratio. I never thought a small 10 inch speaker could keep up with a 12 or 15 inch model but the E10 does. I also have pushed up to 400 watts for an entire evening and and never heard them distort. I did have to lower the bass level at this higher level though. They are expensive but definitely worth the extra cost. Not a lot of features on the E10 either but what passive speaker does.
Posted by Timothy Pocius on May 22, 2012
Was this review helpful?    flag review
