Yorkville Sound

C130 in White Finish

SKU: # 164059   |   Model: # C130W   |    Product Reviews0 Reviews  Write a Review

C130 in White Finish

Additional Photos:

C130 in White Finish
2 models to choose from:
 This product is no longer available.
C130
The trapezoidal shape makes the C130 ideal for install or array mounting in tight locations. Weather resistant plastic enclosure and Mylar components mean the C130 can be used indoors or outdoors, ideal for foyers, patio systems for music and paging systems. Shipped with a rugged proprietary U-bracket for wall or ceiling mounting, they may be the most versatile and cost-effective solution for small installations, or as a repeater or fill cabinet in larger venues.

The C130 is available either in an 8-ohm version, or as a 70-volt multi tapped transformer version designed for fixed installation systems (C130/70). The integrated 70-volt 'matching transformer' allows multiple C130/70's to be connected together without danger of overloading the power amplifier due to impedance drop. The user has a choice of three sensitivity settings (10W, 20W, 30W or bypass). Black or white versions are available.
The C130 is available either in an 8-ohm version, or as a 70-volt multi tapped transformer version designed for fixed installation systems (C130/70). The integrated 70-volt matching transformer allows multiple C130/70's to be connected together without danger of overloading the power amplifier due to impedance drop. The user has a choice of three sensitivity settings (6W, 12.5W, 25W or bypass).

Features:
• 100 watt / 8-ohm Two-Way Installation Loudspeaker
• 6.5-inch Woofer / 1-inch Mylar Dome Tweeter
• 1/4-inch and Binding Post Inputs
• Weather Resistant Plastic Cabinet
• Metal Grille
• Mounting U-Bracket Included
• Available in White (C130W) or Black (C130) Finishes

Specifications:
• System Type: Two Way
• Active or Passive: Passive
• Program Power (Watts): 100
• Nominal Impedance (Ohms): 8 (70 volt optional - C130/70)
• Sensitivity (dB @1Watt/1m): 96
• Max SPL (dB): 116
• Frequency Response (Hz +/- 3db): 75 to 20000
• HF Driver: 1 inch Mylar Dome Tweeter
• LF Driver: 6 1/2 inch 100Wpgm 8-Ohm woofer
• Inputs: 1/4" Jacks x 2 + Binding Posts
• Options: Available in 70-Volt version as C130/70, also in black or white as C130, C130W, C130/70 & C130W/70
• Included Hardware: Mounting Bracket
• Finishes: Available Black or White
• Dimensions (DWH+back, inches): 11.5 x 8.5 x 7.5 x 3.5
• Dimensions (DWH+back, cm): 29 x 22 x 19 x 9
• Weight (lbs/kg): 6.6 / 3.2
