Echo Express SE I - Thunderbolt 3 Edition
Additional Photos:
Product Videos :
1-slot Desktop Thunderbolt 3 Expansion System for PCIe Cards
This compact desktop expansion system supports one professional PCIe card (video capture, audio interface, 6Gb or 12Gb SAS or SATA host bus adapter, 8Gb or 16Gb Fibre Channel, 10Gb or 40Gb Ethernet, or RAID controller) and connects it to your computer through a single Thunderbolt 3 cable. The Echo Express SE I has a small footprint, yet it is large enough to support nearly every Thunderbolt 3-compatible PCIe 3.0, PCIe 2.0, and PCIe 1.1 card available.
Echo Express SE I (Thunderbolt 3 Edition) features a 40Gbps Thunderbolt 3 interface, which offers double the PCIe bandwidth and connectivity of Thunderbolt 2, and yields up to 2750 MB/s of bandwidth, enabling it to support 4K video capture and processing cards at high frame rates, and 16Gb FC cards and dual-port 10GbE cards at full performance.
Features
• Use high-performance PCIe cards with any computer with a Thunderbolt 3 port
• One PCIe 3.0 x8 Slot - Supports one half-length+ (up to 7.75 inches long), full-height, single-width PCIe card (plus one daughter card)
• 40Gbps Thunderbolt 3 Interface offers 2750 MB/s of PCIe bandwidth, doubling the performance of Thunderbolt 2
• Takes up little space on the desktop, but large enough to support nearly every Thunderbolt-compatible PCIe card, at full performance
• Two Thunderbolt 3 Ports - One port connects to computer; second port supports daisy-chaining of up to five additional Thunderbolt peripheral devices
• Remarkably Quiet - Temperature-controlled, variable-speed fan automatically and quietly cools the card
• Energy Saver Mode - Powers on/off automatically with the computer
• Rugged Aluminum Housing - Provides robust and secure protection
• Daisy chain port provides up to 15W of power to connected peripherals
Specifications
Form Factor: Desktop expansion system
External Connectors:
- Two Thunderbolt 3 ports
- 12V power port
Expansion Slot: One PCIe 3.0 slot; x8 mechanical; x4 electrical (Thunderbolt 3 spec)
PCIe Cards Supported:
- One half-length (up to 7.75 inches long), single-width, full-height x8 PCIe card
- One daughter card
Power Adapter: Universal 60W, 100-240V, 50-60 Hz, NRTL Certified
Operating Temperature: 0C to 35C (32F to 95F)
Dimensions (WxDxH): 5.63 x 8.63 x 3.5 in. (14.29 x 22.01 x 8.85 cm)
Weight: 2.6 lbs. (1.18 kg)
RoHS Compliant: Yes
*Note: Windows computers require the latest BIOS and Thunderbolt drivers to support this product. Check with your computer manufacturer for updated information.
Package Contents
- Echo Express SE I (Thunderbolt 3 Edition)
- Universal power adapter
- Power cord
- 0.7-meter Thunderbolt 3 (40Gbps) cable
- ThunderLok 3 Thunderbolt Connector Retainer Clip (2)
- Documentation
