Celestion G12 V-Type 12'' 70W Speaker - 8 Ohm
Additional Photos:
Product Videos :
YouTube Video
Great Additions
Description
Combining decades of experience with advanced measurement and analysis the V-Type has been built using a carefully balanced 'recipe' of old and new design techniques. It produces a heady exciting modern vintage sound that just makes you want to keep on playing: a guitar speaker that delivers authentic Celestion tone whatever your style. The V-type is a sweet sounding speaker with a superbly balanced tonal signature that imparts a vintage musicality to your tone. Clean sounds are true across the lows mids and highs with just enough upper-mid chime and HF sparkle to add clarity and definition. Crank it up for a sizzling overdrive and raw rock tones with plenty of mid-band warmth to give body and substance to lead note playing.
Specifications
Nominal Diameter: 12in/305mm
Nominal Power Rating: 70W
Nominal Impedance: 8Ω
Sensitivity: 98dB
Frequency Range: 70-5000 Hz
Resonance frequency Fs: 75Hz
DC resistance, Re: 7.3Ω or 12.9Ω
Voice coil diameter (mm): 44mm
Voice coil diameter (in): 1.75in
Chassis Type: Pressed steel
Magnet Type: Ceramic
Magnet Weight: 31oz/0.88Kg
Voice coil material: Round copper
Mounting Information
Diameter: 12.2in/309mm
Magnet structure diameter: 5.3in/134mm
Mounting slot dimensions: ⌀ 0.31in/7.9mm
Mounting slot PCD: 11.7in/297mm
Number of mounting slots: 8
Overall Depth: 4.84in/123mm
Cut-out diameter: 11.1/283mm
Unit Weight: 7.2lb/3.3kg
Specifications
Nominal Diameter: 12in/305mm
Nominal Power Rating: 70W
Nominal Impedance: 8Ω
Sensitivity: 98dB
Frequency Range: 70-5000 Hz
Resonance frequency Fs: 75Hz
DC resistance, Re: 7.3Ω or 12.9Ω
Voice coil diameter (mm): 44mm
Voice coil diameter (in): 1.75in
Chassis Type: Pressed steel
Magnet Type: Ceramic
Magnet Weight: 31oz/0.88Kg
Voice coil material: Round copper
Mounting Information
Diameter: 12.2in/309mm
Magnet structure diameter: 5.3in/134mm
Mounting slot dimensions: ⌀ 0.31in/7.9mm
Mounting slot PCD: 11.7in/297mm
Number of mounting slots: 8
Overall Depth: 4.84in/123mm
Cut-out diameter: 11.1/283mm
Unit Weight: 7.2lb/3.3kg
