Make Noise Optomix Music Synthesizer Module

The Optomix music synthesizer module is a two channel Low Pass Gate, providing simultaneous voltage control over amplitude and frequency content of a signal. It is in essence, a Voltage Controlled Filter Amplifier (VCFA) that has an extremely organic response to control signals. The Low Pass Gate is a classic West Coast synthesis circuit.

Features

• Damp circuit updated to accept audio as well as CV allows for patching side-chain compression
• STRIKE INput allows use of Gate signal to trigger Low Pass Gate circuit, "plucking" or "striking" the vactrol
• DAMP and STRIKE parameters combine to allow for easy programming of percussive sounds (sharp Attack w/ Voltage Controlled Decay)
• Normalization of a positive offset to the Channel inputs allows for level-shifting of CV, Envelope Generator and even subtle non-symmetrical clipping of signals
• Summing stage with an AUXiliary IN allows for chaining of multiple units creating larger mixes
• Part of a decentralized mix console integrated throughout the system along with X-PAN, modDemix, Dynamix, and RxMx
• Direct coupled, process audio or control signals
• Utilizes 4 vactrols

Specifications

Width: 8hp
Max Depth (incl. power cable): 34mm
Power: 25mA@ +12V / 25mA @ -12V
