Waldorf
Quantum MK2 61-Key 16 Voice Hybrid Synthesizer Keyboard
Additional Photos:
Product Videos :
YouTube Video
The legendary synthesizer technology of the Waldorf Quantum now with new features.
3 Oscillators offer five synthesis algorithms each:
• Waldorf-style Wavetables with the latest additions from Nave, including speech synthesis and wavetable generation from audio samples
• Classic Synthesizer Waveforms with multiple waves for an ultra fat sound right out of the oscillators
• Granular Sampler with multi sampling plus traditional sampling mode
• Resonator for virtual sound sculpting
• New Kernel synthesis with possibilities from classic 6 operator FM to innovative audio rate wavetable modulations
Quantum's ergonomic and intuitive user panel supports an artist's workflow with elegance. The carefully crafted array of aluminium knobs and encoders surround a high-resolution multi touch display.
To help understand functional correlations between one knob and another, each control knob is individually illuminated by a multi colour LED. This makes it instantly obvious when viewing complex settings and modulation settings, where related parameters can be adjusted quickly and efficiently. With the help of the central display, precise settings can be handled with ease, much the same as the experience when using your cutting edge computer tablet.
Sound designers that have contributed to a multi-facetted factory sound set include: Richard Devine, Howard Scarr, Reinhold Heil, BT, Matt Johnson, Joerg Huettner, Kevin Schroeder, Sascha Dikiciyan, Kurt Ader, Mike Huckaby, Thorsten Quaeschning u.v.m.
• 61 Keys high-quality Fatar TP/8SK keyboard, polyphonic aftertouch
• 8 voices with analog filter, up to 16 voices with digital filters
• Dual timbral: split or layered mode with separate stereo audio outputs
• 3 stereo digital oscillators each capable of five synthesis algorithms
• Wavetable: Waldorf style with latest additions from Nave including speech synthesis, wavetable generation from audio and new features
• Waveform: Waveform with up to 8 simultaneous waves per Oscillator in detuned or chordal mode with hard-sync, warp & PWM as well as tunable noise
• Particle: Sampler in traditional and granular mode using multi-samples or live input
• Resonator: Exciter using multi-sampling plus filter bank sound model.
• New Kernel synthesis with possibilities from classic 6 operator FM to innovative audio rate wavetable modulations
• Two analogue lowpass filters per voice each in 24 or 12 dB configuration using innovative link modes, or alternatively two digital multi-mode filters
• Digital former: Additional digital algorithms per voice like comb filter, high-pass, band-pass & notch filters (Nave, Largo or PPG models), bit-crusher, drive and more
• Flexible routing system for order of filters & digital former and individual oscillator routings
• 6 LFOs in poly and global mode with extensive parameter set
• 6 loopable envelopes
• Komplex: multistage LFO/envelope modulator
• Extensive modulation matrix with 40 slots and easy via-controller assignments
• Intuitive modulation assignment via panel elements and control LEDs
• Master effect rack of 5 slots for each timbre choosing from FX like phaser, flanger, chorus, reverb, drive, eq and more.
• Compressor for main output
• Step sequencer with step recording, parameter automation and scale-based pitch quantization
• Microtonal pitch configurations capable of importing Skala scl files
• Capable of polyphonic aftertouch via internal keybed or external MIDI inputs
• Chord and latch buttons
• Unisono mode
• Module-based preset system for effects, oscillators, step-sequenzer and Komplex modulator
• Single-function potentiometer and encoder controls for intuitive editing
• Visualisation and deeper sound editing via context-sensitive high-resolution capacitive multi-touch display
• Spectrum Analyzer and Oscilloscope at various processing stages
• Up to 10,000 sound patch capacity organized by banks, attributes, author and patch number.
• Favourites lists for quick recall of sound patches like for set-lists etc.
• Pre-loaded with wide variety of patches by acclaimed sound designers
• MIDI output of local keyboard, wheels and assignable panel elements
• Automation of sound parameters from MIDI inputs via MIDI CC learn function
• Recording of samples from audio inputs or self-recording of audio outputs
• 4 GB internal Flash memory for presets and wavetables, 59GB internal sample storage
• Pre-loaded with approx. 2 GB sample data
• On board audio file editor
• Export & import of presets, sample & wavetable via SD card or USB drive
• Import of Nave presets and selected legacy FM .syx files
• Mod wheel can be assigned to any parameter which can be modulated in the matrix or via quick assign
• Pitch wheel can be assigned to each oscillator individually
• Weight: 17.8kg
• Dimensions: 1006 x 401 x 131 mm
Sampling capabilities:
Each of the 3 Oscillators of a single timbre can be used in one of three modes using samples:
• Stereo Multi-Sampler with looping and reverse playback
• Granular Sampler with extensive parameter set
• Resonator model using sampler as exciter
• Samples are organized using key and velocity maps, selections rules like round robin, random etc., and individual pitch, gain and pan settings.
• Samples are stored in internal Flash memory of 59GB capacity pre-filled with 2GB specially made for Quantum factory samples.
• New samples can be recorded from external stereo audio inputs, or from self-recording Quantums own engine.
• Samples can also be imported an stored to internal Flash via SD card or USB drive using WAV and AIFF file format (44.1kHz sample rate).
• The Quantum allows for a huge range of sample-based sound design capabilities from classical synths sounds to uncharted territories.
It's worth noting that the sample use in the Quantum is always within a synthesizers sonic context, and it is not meant to work as a bread and butter sample keyboard to play back like traditional sampling instruments nor third party libraries.
Huge range of arpeggiator parameters:
• 7 Algorithms to choose from like up, down, random etc.
• Octave range
• 7 Sort Orders
• 3 Velocity Modes
• Gate length
• Swing
• BPM
• Beat Division
• Rhythmic patterns
• Reset Modes
• Keyboard Latch chordal and non-chordal
• Individual patterns can be created in the step sequencer including transpositions and scale quantisations.
Connections:
• 2x stereo audio outputs for main and aux timbres
• Stereo audio input for sample recording and real-time processing
• High-Quality 24bit A/D and D/A converters
• Headphone out with separate level adjustment
• Sustain pedal input
• Control pedal connector also capable of CV input (0-5V sensitivity)
• USB host type A connector for interfacing MIDI controller or USB drives for sample/preset exchange and software updates
• USB device type B connector for interfacing computer or other class-compliant MIDI USB hosts like iOS devices
• SD Card for sample/preset exchange and software updates
• DIN MIDI In, Out & Thru
• Integrated power supply unit
- As with the Iridium keyboard, the Quantum MK2 now also features a new FATAR TP/8SK keyboard with 61 semi-weighted keys and polyphonic aftertouch.
- While monophonic aftertouch makes all played notes respond in the same way, polyphonic aftertouch provides specific modulation of individual notes.
- The internal flash memory for samples storage has also been expanded to 59GB.
- The flexibility emanating from Quantum's powerful oscillators and their interaction with one another is simply breath-taking. Stretching from classic analog, with precise sample playback, through to harsh or animated digital sounds, escalating all the way up to sound and sequence clusters, can only be achieved with a huge modular synthesizer system or modern plug-ins.
3 Oscillators offer five synthesis algorithms each:
• Waldorf-style Wavetables with the latest additions from Nave, including speech synthesis and wavetable generation from audio samples
• Classic Synthesizer Waveforms with multiple waves for an ultra fat sound right out of the oscillators
• Granular Sampler with multi sampling plus traditional sampling mode
• Resonator for virtual sound sculpting
• New Kernel synthesis with possibilities from classic 6 operator FM to innovative audio rate wavetable modulations
Quantum's ergonomic and intuitive user panel supports an artist's workflow with elegance. The carefully crafted array of aluminium knobs and encoders surround a high-resolution multi touch display.
To help understand functional correlations between one knob and another, each control knob is individually illuminated by a multi colour LED. This makes it instantly obvious when viewing complex settings and modulation settings, where related parameters can be adjusted quickly and efficiently. With the help of the central display, precise settings can be handled with ease, much the same as the experience when using your cutting edge computer tablet.
Sound designers that have contributed to a multi-facetted factory sound set include: Richard Devine, Howard Scarr, Reinhold Heil, BT, Matt Johnson, Joerg Huettner, Kevin Schroeder, Sascha Dikiciyan, Kurt Ader, Mike Huckaby, Thorsten Quaeschning u.v.m.
Specifications
• Hybrid Digital/Analog Polyphonic Synthesizer• 61 Keys high-quality Fatar TP/8SK keyboard, polyphonic aftertouch
• 8 voices with analog filter, up to 16 voices with digital filters
• Dual timbral: split or layered mode with separate stereo audio outputs
• 3 stereo digital oscillators each capable of five synthesis algorithms
• Wavetable: Waldorf style with latest additions from Nave including speech synthesis, wavetable generation from audio and new features
• Waveform: Waveform with up to 8 simultaneous waves per Oscillator in detuned or chordal mode with hard-sync, warp & PWM as well as tunable noise
• Particle: Sampler in traditional and granular mode using multi-samples or live input
• Resonator: Exciter using multi-sampling plus filter bank sound model.
• New Kernel synthesis with possibilities from classic 6 operator FM to innovative audio rate wavetable modulations
• Two analogue lowpass filters per voice each in 24 or 12 dB configuration using innovative link modes, or alternatively two digital multi-mode filters
• Digital former: Additional digital algorithms per voice like comb filter, high-pass, band-pass & notch filters (Nave, Largo or PPG models), bit-crusher, drive and more
• Flexible routing system for order of filters & digital former and individual oscillator routings
• 6 LFOs in poly and global mode with extensive parameter set
• 6 loopable envelopes
• Komplex: multistage LFO/envelope modulator
• Extensive modulation matrix with 40 slots and easy via-controller assignments
• Intuitive modulation assignment via panel elements and control LEDs
• Master effect rack of 5 slots for each timbre choosing from FX like phaser, flanger, chorus, reverb, drive, eq and more.
• Compressor for main output
• Step sequencer with step recording, parameter automation and scale-based pitch quantization
• Microtonal pitch configurations capable of importing Skala scl files
• Capable of polyphonic aftertouch via internal keybed or external MIDI inputs
• Chord and latch buttons
• Unisono mode
• Module-based preset system for effects, oscillators, step-sequenzer and Komplex modulator
• Single-function potentiometer and encoder controls for intuitive editing
• Visualisation and deeper sound editing via context-sensitive high-resolution capacitive multi-touch display
• Spectrum Analyzer and Oscilloscope at various processing stages
• Up to 10,000 sound patch capacity organized by banks, attributes, author and patch number.
• Favourites lists for quick recall of sound patches like for set-lists etc.
• Pre-loaded with wide variety of patches by acclaimed sound designers
• MIDI output of local keyboard, wheels and assignable panel elements
• Automation of sound parameters from MIDI inputs via MIDI CC learn function
• Recording of samples from audio inputs or self-recording of audio outputs
• 4 GB internal Flash memory for presets and wavetables, 59GB internal sample storage
• Pre-loaded with approx. 2 GB sample data
• On board audio file editor
• Export & import of presets, sample & wavetable via SD card or USB drive
• Import of Nave presets and selected legacy FM .syx files
• Mod wheel can be assigned to any parameter which can be modulated in the matrix or via quick assign
• Pitch wheel can be assigned to each oscillator individually
• Weight: 17.8kg
• Dimensions: 1006 x 401 x 131 mm
Sampling capabilities:
Each of the 3 Oscillators of a single timbre can be used in one of three modes using samples:
• Stereo Multi-Sampler with looping and reverse playback
• Granular Sampler with extensive parameter set
• Resonator model using sampler as exciter
• Samples are organized using key and velocity maps, selections rules like round robin, random etc., and individual pitch, gain and pan settings.
• Samples are stored in internal Flash memory of 59GB capacity pre-filled with 2GB specially made for Quantum factory samples.
• New samples can be recorded from external stereo audio inputs, or from self-recording Quantums own engine.
• Samples can also be imported an stored to internal Flash via SD card or USB drive using WAV and AIFF file format (44.1kHz sample rate).
• The Quantum allows for a huge range of sample-based sound design capabilities from classical synths sounds to uncharted territories.
It's worth noting that the sample use in the Quantum is always within a synthesizers sonic context, and it is not meant to work as a bread and butter sample keyboard to play back like traditional sampling instruments nor third party libraries.
Huge range of arpeggiator parameters:
• 7 Algorithms to choose from like up, down, random etc.
• Octave range
• 7 Sort Orders
• 3 Velocity Modes
• Gate length
• Swing
• BPM
• Beat Division
• Rhythmic patterns
• Reset Modes
• Keyboard Latch chordal and non-chordal
• Individual patterns can be created in the step sequencer including transpositions and scale quantisations.
Connections:
• 2x stereo audio outputs for main and aux timbres
• Stereo audio input for sample recording and real-time processing
• High-Quality 24bit A/D and D/A converters
• Headphone out with separate level adjustment
• Sustain pedal input
• Control pedal connector also capable of CV input (0-5V sensitivity)
• USB host type A connector for interfacing MIDI controller or USB drives for sample/preset exchange and software updates
• USB device type B connector for interfacing computer or other class-compliant MIDI USB hosts like iOS devices
• SD Card for sample/preset exchange and software updates
• DIN MIDI In, Out & Thru
• Integrated power supply unit
Media
Youtube video product demo
Q & A
There are currently no questions for this product.
Reviews
There are currently no reviews for this product. Be the first to write one!
Protect your investment with the Long & McQuade Performance Warranty
A warranty can be a very important factor when making a buying decision. Because repairs can be very expensive in terms of parts and labour costs, manufacturers usually only provide one year limited warranties that generally only cover items that malfunction due to a manufacturer’s defect. With an important purchase such as a musical
instrument or piece of studio gear, however, many people want to have the peace of mind in knowing that their investment will be protected should the product no longer be performing at 100%.
Because of this, Long & McQuade provides our customers with a FREE one-year Performance Warranty on most of our products. The Long & McQuade Performance Warranty supplements the manufacturer’s warranty to ensure that our customers receive complete “no hassle” warranty coverage within their first year.
How does the Long & McQuade Performance Warranty differ from most manufacturers' warranties?
- Performance Guarantee: Normal wear and tear is covered, so your product will be performing as well as the day you purchased it for the entire duration of the coverage. Band and Orchestral Performance Warranty does not include replacing pads or cleaning for woodwind instruments, unless deemed necessary by our repair staff. Ultrasonic cleaning for brass instruments will be provided if deemed necessary by our repair staff, but is not routinely offered under the Performance Warranty.
- Product Replacement: If your product cannot be fixed or costs too much to fix, we will replace it with the equivalent model for no additional charge. If this is not possible, a full refund will be provided.
- No Lemon Policy: Your product will be replaced should the same problem occur multiple times.
- Convenient: Easy drop off and pick up of the product at any Long & McQuade location.
- Guitar Setup: Guitars purchased at Long & McQuade come with 1 free setup, to be redeemed within 1 year for new guitars and 90 days for used guitars.
- Loaners Available: A loaner product may be given while the product is being repaired.
- Power Surge Protection: Your product is covered even if damaged from a power surge.
- Accessory Coverage: Any peripheral devices or accessories that come with your product (i.e. foot pedal, case) are also covered.
- Commercial Use Coverage: Music and recording professionals who purchase gear for “heavy-use” commercial purposes will still be covered.
Long & McQuade reserves the right to restrict the purchase of additional years of Performance Warranty. Used products come with a 3-month Long & McQuade Performance Warranty. Some products (i.e. computers, software, cymbals and other items) are covered only by the manufacturer‘s warranty. Consumables (i.e. strings, reeds, drum sticks, batteries, tubes, cross faders) are excluded as they are designed to be replaced. Cosmetic Damage, Accidental Damage, or problems caused by Humidity or Temperature Issues are not covered. Speakers damaged by overpowering are generally not covered. Our coverage does not provide compensation for loss of use. As of June 2018 the Performance Warranty is no longer transferable. The warranty is only valid in Canada.
Purchasing additional years of coverage
Some manufacturers provide warranties for longer than 1 year; however, these are usually limited warranties that do not provide the same coverage as the Long & McQuade Performance Warranty. Customers interested in more complete and convenient (but not necessarily longer) coverage are still able to purchase additional years of the Performance Warranty.
If you are interested in receiving this coverage for longer than one year, you have the option of purchasing additional years of the Performance Warranty. The pricing is as follows:
- NEW products: 4% of the current new selling price to double the warranty from 1 year to 2 years. 4% for each additional year.
- USED products: 4% of the current new selling price to increase the warranty from 3 months to 1 year. 4% for each additional year.
- GUITARS: 4% of the current new selling price to double the warranty from 1 year to 2 years. 4% for each additional year. $45 maximum. An additional free setup is not included with additional purchased years of Performance Warranty.
- BAND and ORCHESTRAL instruments: 4% of the current new selling price to double the warranty from 1 year to 2 years. 4% for each additional year.
Great Additions
Reserve in Store
| Product | SKU | Qty |
|---|---|---|
| Quantum MK2 61-Key 16 Voice Hybrid Synthesizer Keyboard | 790386 |
