Xvive Audio U7 Saxophone and Trumpet Wireless System U7 Saxophone and Trumpet Wireless System

Sound quality is paramountand without a good microphone, the U7 would be worthless. That's why Xvive refused to compromise in the design of the system's ultra-high-quality supercardioid gooseneck microphone. It's perfectly voiced for sax, trumpet and tromboneand with a max SPL of 142 dB and a sensitivity of -45 dB, you'll hear the natural sound of your instrument wherever you go.

Xvive has built its name on wireless, and understands the importance of reliable performance and top-level fidelity. The U7 system uses the 2.4 GHz band, has 6 channels to ensure you always have options if you encounter interference, and the wireless range is up to 90 feet!

Features

• 2.4 GHz wireless system with a 142 dB SPL supercardioid microphone
• High-resolution 24-bit/48 kHz audio, less than 5 ms latency
• 20 Hz 20 kHz frequency response
• Dynamic range of 108 dB, signal-to-noise ratio of 108 dB
• Up to 5 hours of battery life
• 6 wireless channels
• Wireless range: up to 90 feet (27 m)

Specifications

Microphone
Microphone Type: Supercardioid
Dimensions: 20 mm x 28 mm x 190 mm
Weight: 35 g
Output Plug: 1/8 balanced male TRS (Tip = +3.3V, Ring = -3.3V, Sleeve = ground)
Sensitivity: -45 dB
MAX. SPL: 142 dB

Wireless System
Tuning Bandwidth: 2400 2483.5 MHz
Working Range: 90 ft (indoors)
Frequency Response: 20 Hz 20 kHz (-3dB)
Dynamic Range: 108 dB
Signal-to-Noise Ratio: 108 dB
RF Sensitivity: -88 dBm
Total Harmonic Distortion: 0.2%
RF Output Power: 10 mW E.I.R.P. max
Operating Temperature Range: 0°C to 45°C
Channel Count: 6
Charging Voltage / Current: 5V / 2A
Bit Depth / Sample Rate: 24-bit / 48 kHz
Latency: less than 5 ms

Transmitter
Dimensions: 40 mm x 29 mm x 50 mm
Weight: 35 g
Audio Input Connector: 1/8" balanced TRS female
Maximum Input Level: 3.7 Vp-p
Phantom Power: +/- 3.3V
USB Type: USB Type-C
Antenna Impedance: 50 Ω
Antenna Type: 1/4 wave sleeve dipole, non-removable
Number of Antennas: 1

Receiver
Dimensions: 31 mm x 29 mm x 98 mm
Weight: 92 g
Output Impedance: 470 Ω (1 kHz)
Audio Output Connector: XLR balanced male
Maximum Output Level: 3.6 Vp-p
USB Type: USB Type-C
Antenna Impedance: 50 Ω
Antenna Type: 1/4 wave sleeve dipole, non-removable
Number of Antennas: 2
