Behringer StageConnect Hub with Bus Powering for Personal Monitor Mixers
Additional Photos:
Save time and energy by giving the control to the musicians! Personal monitors also allow for built-in effects, improving sound; built-in microphones, improving both communication and immersion; All controlled with a simplified user interface.
No matter if you're using a single P24 to provide an artist's mix in your studio recording room, or you're deploying a large setup for an orchestra pit with several daisy-chained P24HUBs-- setup and configuration is always a breeze.
The P24HUB is the obvious choice for larger setups especially in touring applications. However, several P24 personal mixers can be daisy-chained without a hub. This is ideal when supporting smaller impromptu gigs.
Specifications
ConnectionsAES50 sync HOST/Master/thru: 2 x RJ45
ULTRANET input/output: 2 x RJ45
StageConnect HOST/Master: 1 x male
StageConnect CLIENT/Slave: 1 x female
StageConnect remote outputs: 4 x male
Analog outputs: 16 x 1/4" TRS
USB: Type B
AES50
Audio channels: 16/24
Sample rate: 44.1 / 48 kHz
Bit depth: 24 bit
Remote power: PoE (IEEE802.3at)
Latency: 146 μs at 44.1 Hz / 125 μs at 48 kHz
Cable length: up to 80 m
StageConnect
Audio channels: 24
Sample rate: 44.1 / 48 kHz
Bit depth: 24 bit
Phantom power : 12 V DC / 18 W
Latency : 146 μs at 44.1 Hz / 125 μs at 48 kHz
Cable: XLR balanced or DMX cable
Cable length : up to 40 m with 110 ohm DMX cable
Power
Power consumption : 125 W
Mains connection : Standard IEC receptacle
