M-Audio 5'' BX5 Graphite Powered Studio Monitor (Single)
Additional Photos:
The combination of carbon fiber woofer and rear porting make the BX5 graphite a standout in low frequency extension and faithful reproduction of your mix. The Carbon Fiber woofer provides low distortion and accurate sound via a high stiffness to weight ratio. The stiffness provides controlled pistonic action for accuracy without distortion. The rear port is tuned precisely to the volume of the cabinet and the capabilities of the woofer extending the 5-inch graphite monitor down to near 50Hz.
Computer Optimized Waveguide
The unique elliptical waveguide of the BX5 graphite provides a wide sweetspot with less off-axis imaging changes as you move across the listening area in your studio. The design is enhanced with computer optimization to ensure the complex curves and radiuses of the elliptical shape maintain consistency in acoustic characteristic.
Specifications
- Woofer: 5-inch carbon fiber- Tweeter: 1-inch natural silk dome
- Total Power: 100 watts (60W LF, 40W HF)
- Frequency Response: 52Hz-35kHz
- Inputs: XLR, 1/4" TRS (balanced), and RCA (unbalanced)
- Acoustic Space Control: Allows for adjusting low-frequency response to suit the listening environment. (0dB/-2dB/-4dB)
- High Frequency Control: Enables adjustment of high-frequency output to match the room acoustics. (+2dB/0dB/-2dB)
- Rear Ported: Optimized for extended low-frequency response
- Computer-optimized tweeter waveguide for precise imaging
- Dimensions: 9.09" W x 11.73" H x 7.24" D
- Weight: 12.35 lbs
