Celestion F12M-150 Triple Cone 12'' 8ohm Speaker

The F12M-150 is a full range, LIVE response speaker, designed for use with amp modellers and IRs. Its unique design features two additional tweeter cones integrated into the main woofer cone (making it "Triple Cone"). This enables the speaker to deliver near full-range frequency performance: from 60Hz up to 12kHz, for a rich and detailed sound, whatever your set-up.

Designed with Celestion's Pro Audio know-how, response is flat and neutral, ensuring no unwanted colourations that could overwhelm the input signal. But with an optimised woofer cone and lighter moving mass the F12M-150 Triple Cone is designed to closely mimic the responsiveness of a traditional guitar speaker, delivering all the tactile feel you would expect from playing through a conventional guitar rig. It's not just FRFR, it's Full Range LIVE Response.

Specifications

Diameter: 12in
Rated impedance: 8Ω
Sensitivity: 97dB
Nominal diameter: 305mm / 12in
Power rating: 150W
Chassis type: Pressed steel
Magnet type: Ceramic
Magnet weight: 0.9kg / 35oz
Voice coil diameter: 2in / 51mm
Voice coil material: Round copper
Frequency range: 60-12,000Hz
Resonance frequency, Fs: 70Hz
DC resistance, Re: 6.07Ω

Mounting Information
Cut-out diameter: 283mm / 11.1in
Diameter: 309mm / 12.2in
Magnet structure diameter: 145mm / 5.7in
Mounting hole dimensions: 7.9mm / 0.31in
Mounting hole PCD: 297mm / 11.7in
Number of mounting holes: 8
Chassis depth (inc gasket): 94mm / 3.7in
Magnet depth: 33mm / 1.3in
Overall depth: 127mm / 5in
Unit weight: 3.6kg / 7.9lb
