Mesa Boogie 5 Band Graphic EQ Pedal

Departments > Guitars > Guitar Effects > Effect Equalizer > Mesa Boogie > 5 Band Graphic EQ Pedal
Add to Wish List
SKU: # 415899
Model: #

BOOGIEGRAPHICEQ

Your Price: $377.00 CDN

Online

In-Store

For well over four decades now the Boogie Five Band Graphic EQ has been at the heart of chart topping guitar sounds and its hard to ignore the impact its now-classic V-Curve has had on modern guitar sounds and popular music. Now we offer this powerful tool in a stand alone pedal format that packs the same shaping power and hand-built in Petaluma, CA quality as those found in our high-end amplifiers.

In the early 70s Boogie sounds were most associated with singing, vocal-inspired lead work as Artists learned the newfound possibilities of its high gain tube preamp and its game-changing sustain. The Graphic EQ aboard most fully loaded Hun-Revs of the day found their sliders set for a subtle widening effect or enhanced Bass response to mimic bigger cabinets with the little 1x12 combo. As the era of Classic Rock faded and the dawn of Metal appeared on the horizon in the late 70s and early 80s, the potential power of this on-board tool began to be fully realized. Graphic-loaded MARK II Boogies became the norm and most of these on-board EQs were used to scoop the mids to extreme levels while boosting lows and highs and this V-Curve became a new standard... the other sound (non-Brit) in Hard Rock and Metal.

Since then MARK III, MARK IV and MARK V Boogies all have their place in Rock history through iconic Artists and the Graphic EQ has been an integral part of their sound. The Five Band Graphic EQ aboard the current MARK V Boogie is again at the forefront of emerging styles as a whole new generation crafts their own unique brand of heavy sounds in Djent and Nu-Metal genres. Now were proud to introduce the stand-alone Pedal version of this piece of Rock history built with the same quality parts and handmade in our Petaluma facility. Now you can incorporate this powerful shaping tool into any setup (including non-guitar applications) whether in the Front End or in an Effects Loop and create your own unique signature Tones. The same long-throw Sliders are used to achieve maximum resolution and finite adjustment. Both INPUT and OUTPUT LEVEL Controls are fitted to ensure optimum matching of both your Source and Destination regardless of your application. Whether used in front of your amplifiers Input or in your Effects Loop, it gives you a footswitchable Tone option you can employ on demand. And when its not engaged, your sound is pure and unaltered thanks to the Hard Bypass Feature.

The Boogie Five Band Graphic runs on one 9 Volt battery and can also be powered by a standard DC Wall Transformer. Now this affordable package brings the power of the Boogie Five Band Graphic and its classic V-Curve Toneas well as near-limitless other Tone possibilitiesto players of all experience levels, musical needs and amplifier brands in a small pedal board-friendly format thats hand-built in the USA using the finest materials. Boogie-ize your rig!

FEATURES

• Designed and Handcrafted in Petaluma, California, USA
• True Bypass On/Off Switching - Bypasses all circuitry when off to ensure no tonal loss
• Input Level Control provides Unity Gain Detent and ability to boost by +6db or cut by -40db
• Output Level Control provides Unity Gain Detent and ability to boost by +6db or cut by -40db
• Slider Controls provide Mesas legendary tone-shaping power with +/- 12db of boost or cut at 80Hz, 240Hz, 750Hz, 2.2Khz and 6.6Khz
• On/Off Status LED
• 9V Battery Powered or Externally Powered (optional) via External Power Jack Input
• Input & Output Jacks (Nominal Input -20db)

SPECIFICATIONS

• Dimensions (W/D/H): 5.78" x 4.76" x 2.30" (146.8mm x 121mm x 58.4mm)
• Weight: 1.6lbs (725.7g) with battery, 1.5lbs (680.4g) without battery
• True Bypass Switching
• Battery Type: 9VDC (one)
• Power Consumption (Current Draw): 9VDC/25mA
• External Power Supply (Not Included):
WARNING!!! To avoid immediate damage and voiding the warranty, the External Power Supply MUST be 9VDC with a NEGATIVE CENTER plug polarity and a jack plug size of 2.1mm x 5.5mm.
• Input Impedance: 1M Ohm (500k Ohm minimum)
• Output Impedance: 10k Ohm

Must have1 of 1 customers found this review helpful

FeaturesProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
QualityProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
ValueProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
OverallProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
Product ExperienceI own it
Closest StoreNorth Vancouver, British Columbia
Pairs great with other amps too. Use it on my Fender Blues D amp and it opens it up amazingly. I call it my secret weapon.
Posted by Tshark on Dec 1, 2018
Was this review helpful?    flag review
