Mesa Boogie Flux-Five Dual Mode OD Pedal w/5-Band EQ

Departments > Guitars > Guitar Effects > Effect Overdrive > Mesa Boogie > Flux-Five Dual Mode OD Pedal w/5-Band EQ
Add to Wish List
SKU: # 415896
Model: #

FLUX-FIVE

Your Price: $479.00 CDN

Online

In-Store

Powerful new EQ version adds our classic Five Band Graphic EQ and footswitchable HI/LO performance Modes featuring separate OUTPUT LEVEL controls to the already versatile FLUX-DRIVE package for increased shaping power and enhanced stylistic versatility.

The reception for the FLUX-DRIVEs fat, smooth, expressive gain has been outstanding among Artists and players alike, and with critical praise backing that up around the globe, it was an obvious recipient for the enhanced power of our Five Band EQ. Introducing the FLUX-FIVE overdrive, a supercharged version of our popular FLUX-DRIVE that features a shrunk-to-size version of our classic Five Band Graphic EQ and new added versatility thanks to footswitchable HI/LO performance Modes. The LO Gain Mode is the original FLUX-DRIVE in every way and now on this wider platform a new higher gain version of this soulful sound appears in the HI Mode. The Graphic EQ allows the popular V-Curve EQ setting to be applied to its layers of thick gain creating a huge, wide Heavy Rock or Metal sound that still retains the FLUXs warm character. The original TREBLE and BASS rotary EQ controls can be used to dial in global enhancements and the combination of the two EQ styles produces signature sounds for any genre.

The Graphic EQ can be applied to both HI and LO Gain Modes enabling you to have a global EQ curve or it can be applied to either gain Mode separately allowing you to have two preset sounds with different EQ shapes and gain signatures to switch between. A HI TRIM pot allows the volume level of HI to be adjusted in relation to the original LO (FLUX-DRIVE) Mode. However you choose to utilize all this potential, the warm rich FLUX-FIVE overdrive is sure to inspire you and bring out your best.

FEATURES

• Designed and Handcrafted in Petaluma, California, USA
• True Bypass On/Off Footswitch bypasses all circuitry when off to ensure no tonal loss
• HI/LO Footswitch provides instant access between HI & LO (Gain) Modes for greater musical versatility
• Gain Control allows you to dial in the perfect amount of vocal-overdrive, dynamic to sustaining
• Bass & Treble Controls provide +/- 12db of EQ boost or cut for exceptional overall tone shaping
• 5-Band Graphic EQ provides Auto-Assignability to either Mode (HI or LO) via Independent On/Off Switches and Mesas legendary tone-shaping power with +/- 12db of boost or cut at 80Hz, 240Hz, 750Hz, 2.2Khz and 6.6Khz
• HI Trim Level Control with LED Indicator provides an Independent Level Boost when HI Mode is activated
• Master Level Control provides an overall variable range of signal boost up to +20db
• On/Off Status LED with Dual Color LEDs to indicate the active Mode (LO = Yellow / HI = Red)
• 9V Battery Powered or Externally Powered (optional) via External Power Supply Input Jack
• Input & Output Jacks (Nominal Input -20 db)

SPECIFICATIONS

• Dimensions (W/D/H): 5.78" x 4.76" x 2.30" (146.8mm x 121mm x 58.4mm)

• Weight: 1.7lbs (771g) with battery, 1.6lbs (725.7g) without battery
• True Bypass Switching
• Battery Type: 9VDC (one)

• Power Consumption (Current Draw): 9VDC/25mA
• External Power Supply (Not Included):
WARNING!!! To avoid immediate damage and voiding the warranty, the External Power Supply MUST be 9VDC with a NEGATIVE CENTER plug polarity and a jack plug size of 2.1mm x 5.5mm.
• Input Impedance: 1M Ohm (500k Ohm minimum)
• Output Impedance: 10k Ohm

Great EQ, grit crunch pedal, simple, easy, reliable0 of 0 customers found this review helpful

FeaturesProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
QualityProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
ValueProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
OverallProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
Product ExperienceI own it
Closest StoreToronto (Bloor St.), Ontario
Mesa Boogie nailed the 5 band EQ idea a long time ago. Any more, it would be too complicated to get quick good results. Any less and it would be only a glorified bass/treble control. Really good tone shaping. 99% of settings are useable. The basic crunch overdrive seems to nail that sound. The over-the-top overdrive setting seems too much. I can run the crunch setting into a tube crunch amp and get a really hot sound that is useable. Too much gain and it gets more musically unusable as you go off the deep end. So this device has superb EQ and crunch. Easy to dial in and simple easy good reliable footswitch on and off. It has to work every time on stage and it does.
Posted by Retired Schmuck on Jul 21, 2020
Was this review helpful?    flag review

Best Overdrive I've Tried2 of 2 customers found this review helpful

FeaturesProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
QualityProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
ValueProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
OverallProduct ratingProduct ratingProduct ratingProduct ratingProduct rating
Product ExperienceI own it
Closest StoreCalgary, Alberta
This might not be ideal for players looking for a transparent overdrive, but it's great for dialing in a smooth tone with single coils and a clean amp. The 5-band EQ is my favorite feature.
Posted by anonymous on Mar 20, 2015
Was this review helpful?    flag review
