Fender Quantum LT 4 Audio Interface
Additional Photos:
Description
With custom low-latency drivers and pristine converters, LT 4 ensures your recordings sound professional and responsive. Software integration with Fender Studio Pro and Universal Control allows you to remotely control direct monitoring from your computer, tablet, or phone. Loopback makes podcasting and streaming easy, while standalone "Mixer Mode" adds utility when youre not using a DAW.
Features
• 4x2 USB audio interface with custom low-latency drivers• Two MAX-HD microphone preamps with 75 dB gain range
• Dual Fender-designed instrument inputs for guitars, basses, and more
• Balanced TRS outputs and powerful headphone output
• Integrated line inputs for connecting external gear
• Remote direct monitoring control via Fender Studio Pro and Universal Control
• Loopback functionality for streaming and content creation
• Standalone "Mixer Mode" for simple, computer-free mixing
• Built-in MyFender access for account setup, software downloads, and support
Specifications
ElectronicsInputs: Four - (Two 1/4" TS, Two XLR Combo Mic/Line)
Headphone Jack: Two - 1/4" TRS Female Stereo
Line Out: Two - 1/4" Balanced (Left and Right)
Connectivity: USB-C®
Voltage: 120V
Phantom Power: +48 VDC
Performance
Digital Audio Bit Depth: 24 Bit
Digital Audio Dynamic Range: 115 dB
Inputs
Instrument Input Connection Type: 1/4" TS Female, Unbalanced, Hi-Z
Instrument Inputs Frequency Response: 20 Hz to 20 kHz
Instrument Inputs Maximum Level: +12.9 dBu
Line Input Connection Type: XLR/TRS Mic/Line Combo
Line Inputs Dynamic Range: 115
Line Inputs Frequency Response: 20 Hz to 20 kHz
Line Inputs Gain Range: -20 dB to +20 dB
Line Inputs Maximum Level: +15 dBu
Line Inputs Total Harmonic Distortion: 0.001%
Microphone Input Connection Type: XLR Female (Combo), Balanced
Microphone Preamp Dynamic Range: 115 dB
Microphone Preamp Equivalent Input Noise: -128.9 dBu
Microphone Preamp Frequency Response: 20 Hz to 20 kHz
Microphone Preamp Gain Control Range: 75 dB
Microphone Preamp Maximum Input Level: +14 dBu
Microphone Preamp Total Harmonic Distortion: 0.001%
Outputs
Headphone Outputs Dynamic Range: 113 dB
Headphone Outputs Frequency Response: 20 Hz to 20 kHz
Headphone Outputs Maximum Output: 46mW @ THD+N 0.007%
Headphone Outputs Total Harmonic Distortion: 0.002%
Main And Line Outputs Dynamic Range: 115 dB
Main And Line Outputs Frequency Response: 20 Hz to 20 kHz
Main And Line Outputs Maximum Level: +15 dBu (Balanced)
Main And Line Outputs Total Harmonic Distortion: 0.002%
Main Outputs Connection Type: 1/4" TRS Female
