Midas 24 Output Stage Box, 24 XLR Outs w/AES50

DL152 is a 5U 19" fixed-configuration rack I/O unit with 24 line level outputs and delivers legendary MIDAS sound quality. Featuring two AES50 network ports providing dual redundancy, the DL152 is the ideal partner to all MIDAS PRO and M32 Series digital consoles, enabling a digital snake connection from Front of House to stage.

L152 features 24 active servo-balanced low impedance line level outputs with high output current capability for driving long cable runs. The outputs feature an automatic mute facility if the audio signal path is muted by the mixing console operator, and individual LED indicators are provided for each output connector.

Features:

• 24 electronically balanced low impedance line level outputs
• Remote operation up to 100 m via CAT5/5e cable
• Selectable 96 kHz or 48 kHz sample rate operation
• All settings programmable from front panel controls or console
• PSU status indicator LEDs and configuration LCD display on front panel
• Supports dual redundant AES50 networks
• Features Neutrik etherCON• AES50 network ports
• Rugged 2U rackmount chassis for durability in portable applications
• Auto-ranging universal switch-mode power supply
• 3-Year Warranty Program*
• Designed and engineered in England
