Roland
D-05 Boutique Linear Synth Module
Additional Photos:
Product Videos :
FEATURES
- Perfect sonic recreation of the D-50 from the makers of the original
- Digital Circuit Behavior (DCB) faithfully captures every detail
- Authentic user interface including joystick control
- All the original presets plus fresh new sounds
- Compatible with original D-50 patches
- 64-step, polyphonic onboard sequencer and arpeggiator
- Rugged construction with metal front panel
- Highly portable for mobile music making
- Battery operated (4 x AA) or USB powered
- Built-in powered mini-speaker for instant enjoyment
- Compatible with optional Roland Boutique accessories
SPECIFICATIONS
Maximum Polyphony: 16 Voice Polyphonic Linear Synthesizer
Patch/Pattern Memory:
Preset Patch: 64 x 6
User Patch: 64 x 8
Pattern: 64
Controllers:
VOLUME knob
Ribbon controllers C1, C2
Joystick
FUNCTION button
PRESET/USER button
PARTIAL BALANCE/EDIT select button
UPPER/LOWER/VALUE/LOCAL indicator
Left cursor/F1/F2/right cursor button and indicator
CHASE button and indicator
PORTAMENTO button and indicator
EDIT button
EXIT button
SEQUENCER button and indicator
WRITE button
INCREMENT button
DECREMENT button
Numerical keys (0-9, SHIFT, ENTER)
PATCH BANK buttons and indicators (1-8)
PATCH NUMBER buttons and indicators (1-8)
Power switch
Step Sequencer: 64 steps
Arpeggio:
Type: 1 Oct (UP, U+D, DOWN), 2 Oct (DOWN, U+D, UP)
Step: 1/4, 1/8, 1/16, 1/4T, 1/8T, 1/16T
Display: 16 characters 2 line LCD
Connectors:
PHONES jack: stereo miniature phone type
OUTPUT jack: stereo miniature phone type
MIX IN jack: stereo miniature phone type
MIDI (IN, OUT) connectors
USB port: Micro-B type (Audio, MIDI)
Power Supply:
Rechargeable Ni-MH battery (AA, HR6) x 4
Alkaline battery (AA, LR6) x 4
USB bus power
Current Draw: 500 mA (USB bus power)
Expected battery life under continuous use: Rechargeable Ni-MH battery: Approx. 5 hours
*This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.
Accessories:
Owner's Manual
Leaflet "USING THE UNIT SAFELY"
Alkaline battery (AA, LR6) x 4
Options (sold separately):
Keyboard Unit: K-25m
Boutique Dock: DK-01
Size and Weight:
Dimensions (WxDxH): 300 x 128 x 46 mm (11-13/16 x 5-1/16 x 1-13/16 inches)
Weight (including batteries): 900 g (2 lbs)
