The ELX200 series offers professional Electro‑Voice audio quality, precision control, and robust, EV‑engineered components in an ultra‑lightweight package - a truly potent blend of performance and portability. Get the smooth clarity of the EV sound in the right size to suit your needs: with 10‑inch, 12‑inch, and 15‑inch two‑way models, and 12‑inch and 18‑inch subwoofers available, ELX200 is a flexible, feature‑rich choice for DJs, mobile entertainers, bands, and musicians.

ELX200-10 Features
* 1200 W (Peak), 127 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices.
* 1.4 inch DH-1L (1 inch exit) titanium compression driver for extended transparent high-frequency response.
* High-output EVS-10M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
* EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
* Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX two-handle design for easy lifting.

ELX200-10 Specifications
Speaker Type: Full-Range
Minimum Impedance: 7.2Ω
HF Transducer: DH-1L 1-inch titanium compression driver
Woofer Size: 10 inch
Frequency Response (-3 dB): 65 Hz - 20 kHz
Frequency Range (-10 dB): 49 Hz - 22 kHz
Max. SPL/1m (calc): 127dB
Coverage (Nominal -6 dB) H: 90
LF Transducer: EVS-10M 254 mm (10 in)
Coverage (Nominal -6 dB) V: 60
Crossover Frequency: 2 kHz
Recommended High-Pass Frequency: 55Hz
Nominal Impedance: 8Ω
Axial Sensitivity (SPL, 1 W @ 1 m): 90dB

Power Rating: 1200W
Power Handling (Continuous / Peak): 300 W/1200W

Suspension: (3) M10 suspension points
Connector Type: Dual NL4
Enclosure Material: Polypropylene Composite
Grille: 18 AWG steel with powdercoat
Available Colour: Black or White

Dimensions (H x W x D): 20.91" x 12.99" x 12.56" (531mm x 330mm x 319mm)
Weight: 29.54lbs (13.4kg)
