***NO SOFTWARE INCLUDED***

2-in / 2-out, 24-bit / 192 kHz USB audio interface with included software and DAW for Mac, PC, iPad, and iPhone.

Everything you need to start recording music with legendary sound.

Start recording right out of the box with a high-quality 2-in / 2-out USB audio interface, award-winning DAW, Volt 2 gives you the sound of your favorite records.

Key Benefits

* Get the rich, full album-ready sound of UAs classic 610 preamps with Vintage mode
* Capture every detail and nuance of your performance with up to 24-bit / 192 kHz quality and crystal-clear converters
* Level up your recording and mixing skills with tips and tutorials for beginners to advanced users
* Take Volt anywhere with support for MacOS, Windows, iPad, iPhone (iOS 14+) for laptops, desktop, and mobile recording*

Enjoy Studio-Quality Sound Anywhere
Powered by Universal Audios award-winning preamp and converter technology, Volt elevates any recording with pro studio sound, even for those just starting.

Get Analog Warmth with Vintage Mic Preamp Mode
Plug in your mic or instrument, press the Vintage button, and experience the rich, full sound of the renowned UA 610 tube preamp one of the most recorded mic preamps of all time.

Features:

* Desktop 2-in / 2-out USB audio interface with 2 preamps and class-leading 24-bit / 192 kHz audio conversion
* Vintage Mic Preamp mode for recording your voice, guitar, or any instrument with the rich, full sound of an iconic UA tube preamp
* Listen in realtime as you record with Direct Monitoring for latency-free recording
* Bus-powered and class-compliant for hassle-free set-up with Mac, PC, iPad, and iPhone using the included USB-C to USB-A cable*
* Studio-quality headphone amplifier for loud, clear monitoring
* 48V phantom power for condenser microphones
* Stylish, rugged construction built to withstand years of use
* Connect MIDI controllers, synths, and drum machines through the onboard 1-in / 1-out MIDI connection

Specifications

I/O
Monitor Outputs: Two (one stereo pair)
Headphone Output: One stereo
USB: One USB 2.0 port (USB Type-C connector)
MIDI: In, Out (two 5-pin DIN connectors)

A/D D/A Conversion
Supported Sample Rates (kHz): 44.1, 48, 88.2, 96, 176.4, 192
Bit Depth: 24

ANALOG I/O

Microphone Input(s)
Frequency Response: 20 Hz to 20 kHz, 0.1 dB
Dynamic Range (Aweighted): 112 dB
THD + Noise (1 kHz @ -1 dBFS): -103 dB (0.0007 %)
Equivalent Input Noise (150 Ohms, A-weighted): -127 dBu
Maximum Input Level: 9 dBu
Input Impedance: 3 Kilohms
Available Gain: 55 dB
Phantom Power: +48V (switchable)
Connector Type: XLR Female, pin 2 positive

Instrument Input(s)
Frequency Response: 20 Hz to 20 kHz, 0.05 dB
Dynamic Range (Aweighted): 111 dB
THD + Noise (1 kHz @ -1 dBFS): -84 dB (0.006 %)
Maximum Input Level: 12.5 dBu
Input Impedance: 1 Megohms
Available Gain: 55 dB
Connector Type: TS unbalanced

Line Input(s)
Frequency Response: 20 Hz to 20 kHz, 0.05 dB
Dynamic Range (Aweighted): 111 dB
THD + Noise (1 kHz @ -1 dBFS): -102 dB (0.0008 %)
Maximum Input Level: 22 dBu
Input Impedance: 15 Kilohms
Available Gain: 55 dB
Connector Type: TRS balanced or TS unbalanced

Monitor & Line Output(s)
Frequency Response: 20 Hz to 20 kHz, 0.1 dB
Dynamic Range (Aweighted): 110 dB
THD + Noise (1 kHz @ -1 dBFS): -102.5 dB (0.00075%)
Maximum Output Level: 15 dBu
Output Impedance: 100 Ohms
Connector Type: TRS balanced or TS unbalanced

Headphone Output(s)
Frequency Response: 20 Hz to 20 kHz, 0.1 dB
Dynamic Range (Aweighted): 110 dB
THD + Noise (1 kHz @ -1 dBFS): -102.5 dB (0.00075%)
Maximum Output Level: 15 dBu
Output Impedance: 100 Ohms
Connector Type: TRS stereo unbalanced

SYSTEM REQUIREMENTS

macOS & Windows
Available USB 2.0 (or higher) port
USB cable (included)
Intel, AMD, or Apple silicon processor
Windows 10 or Windows 11 (64-bit editions)
macOS Catalina 10.15 or newer operating system
Internet connection for software downloads

iPad & iPhone
iPadOS / iOS 14 or newer

*Requires external Volt power supply and an Apple Lightning to USB Camera Adapter (except iPads with USB-C).
