CUBE-20XL BASS: Bass Amplifier
XL Power for Bassists!
Just as the CUBE guitar-amp family received an XL upgrade, now its time for the CUBE BASS line to reach XL status. The new CUBE XL BASS amplifiers remain portable and travel friendly, a CUBE tradition, but they benefit from new-generation XL performance enhancements. These new amps deliver a knock-out punch with custom FFP and COSM technology. FFP is one of Rolands core technologies in which each component amp, cabinet, and speaker achieves maximum efficiency and performance for incredible power from a compact body.
The most portable of the family, the CUBE-20XL BASS, features 20 watts of power, an 8-inch custom speaker, six COSM amp models, pro-quality effects (Reverb, Delay, Chorus, Solo, Poly Octave, Compression, and Overdrive), Power Squeezer for big sound at low volume, and 3-band EQ.
* Ultra-compact 20-watt bass amp with custom-designed 8-inch speaker
* Six COSM amp models onboard
* Seven effects, including the new DRIVE and POLY OCTAVE
* POWER SQUEEZER for big, rich sound at low volumes; great for home practice and other volume sensitive environments
* Three-band EQ for fine-tuning your sound
* Built-in bass tuner
SPECS
Rated Power Output: 20 W
Nominal Input Level: BASS INPUT: -10 dBu/1 M ohm / AUX IN: -10 dBu
Speaker: 20 cm (8 inches)
Controls
POWER Switch, SHAPE Switch, TUNER Switch, POWER SQUEEZER Switch
[COMP/DRIVE]
COMP/DRIVE Knob (COMP, DRIVE)
[COSM AMPLIFIER]
TYPE Switch (SUPER FLAT, FLIP TOP, B MAN, BASS360, SESSION, CONCERT 810), GAIN Knob, VOLUME Knob
[EQUALIZER]
BASS Knob, MIDDLE Knob, TREBLE Knob
[EFX/SOLO]
EFX/SOLO Knob (CHORUS, SOLO, POLY OCTAVE)
[DELAY/REVERB]
DELAY/REVERB Knob (DELAY, REVERB)
Indicators: Power, COMP/DRIVE, TUNER, EFX/SOLO, POWER SQUEEZER
Connectors
BASS INPUT Jack (1/4" phone type), AUX IN Jack (Stereo miniature phone type), FOOT SW Jack (TIP:EFX/SOLO, RING:COMP/DRIVE) (1/4" TRS phone type), RECORDING OUT/PHONES Jack (Stereo 1/4" phone type)
Power Consumption: 24 W
Accessory: Owner's Manual
Options (sold separately): Footswitch (BOSS FS-5U, FS-6)
SIZE AND WEIGHT
Width: 335 mm, 13-3/16 inches
Depth: 327 mm, 12-7/8 inches
Height: 335 mm, 13-3/16 inches
Weight: 9.4 kg, 20 lbs. 12 oz.
