Roland - D-05 ROLAND
Description
We have two K25 companion stand/ keyboards that work with this synth here:
www.long-mcquade.com/?page=ViewStoreSpecial&ProductsClearanceID=725212&ViewPrivew=1
www.long-mcquade.com/?page=ViewStoreSpecial&ProductsClearanceID=725208&ViewPrivew=1
The D-05 Linear Synthesizer from Roland is a compact reproduction of their renowned D-50 Linear Synthesizer, first released in 1987. The D-50 is easily one of the most influential keyboards ever made. This revolutionary instrument helped define the sound of the late '80s with its instantly recognizable mix of sampled attacks and synthesized sustaining waveforms, plus built-in chorus, reverb, and EQ. It's the basis of classic tracks in a wide range of genres including synth pop, new wave, new jack, and R&B, and can be heard in countless film scores of the era. With the Roland D-05, you get the iconic sound and dedicated control of the D-50 in a modern device that perfectly recreates the legendary synth down to its finest details.
FEATURES
- Perfect sonic recreation of the D-50 from the makers of the original
- Digital Circuit Behavior (DCB) faithfully captures every detail
- Authentic user interface including joystick control
- All the original presets plus fresh new sounds
- Compatible with original D-50 patches
- 64-step, polyphonic onboard sequencer and arpeggiator
- Rugged construction with metal front panel
- Highly portable for mobile music making
- Battery operated (4 x AA) or USB powered
- Built-in powered mini-speaker for instant enjoyment
- Compatible with optional Roland Boutique accessories
SPECIFICATIONS
Maximum Polyphony: 16 Voice Polyphonic Linear Synthesizer
Patch/Pattern Memory:
Preset Patch: 64 x 6
User Patch: 64 x 8
Pattern: 64
Controllers:
VOLUME knob
Ribbon controllers C1, C2
Joystick
FUNCTION button
PRESET/USER button
PARTIAL BALANCE/EDIT select button
UPPER/LOWER/VALUE/LOCAL indicator
Left cursor/F1/F2/right cursor button and indicator
CHASE button and indicator
PORTAMENTO button and indicator
EDIT button
EXIT button
SEQUENCER button and indicator
WRITE button
INCREMENT button
DECREMENT button
Numerical keys (0-9, SHIFT, ENTER)
PATCH BANK buttons and indicators (1-8)
PATCH NUMBER buttons and indicators (1-8)
Power switch
Step Sequencer: 64 steps
Arpeggio:
Type: 1 Oct (UP, U+D, DOWN), 2 Oct (DOWN, U+D, UP)
Step: 1/4, 1/8, 1/16, 1/4T, 1/8T, 1/16T
Display: 16 characters 2 line LCD
Connectors:
PHONES jack: stereo miniature phone type
OUTPUT jack: stereo miniature phone type
MIX IN jack: stereo miniature phone type
MIDI (IN, OUT) connectors
USB port: Micro-B type (Audio, MIDI)
Power Supply:
Rechargeable Ni-MH battery (AA, HR6) x 4
Alkaline battery (AA, LR6) x 4
USB bus power
Current Draw: 500 mA (USB bus power)
Expected battery life under continuous use: Rechargeable Ni-MH battery: Approx. 5 hours
*This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.
Accessories:
Owner's Manual
Leaflet "USING THE UNIT SAFELY"
Alkaline battery (AA, LR6) x 4
Options (sold separately):
Keyboard Unit: K-25m
Boutique Dock: DK-01
Size and Weight:
Dimensions (WxDxH): 300 x 128 x 46 mm (11-13/16 x 5-1/16 x 1-13/16 inches)
Weight (including batteries): 900 g (2 lbs)
