Yamaha - PSREW400 76 Key Digital Piano

Description

Portable Performance Powerhouse

The flagship model in the PSR-E series is built for playing live. Easy-to-use professional features, 76-key touch response keyboard, new Live! Grand Piano Voice, computer and external storage connectivity, and L/R outputs for connecting to a PA system.

Overview

* 758 high quality voices featuring the new Live! Grand Piano voice
* 12W + 12W amplifiers with 12 cm Bass Reflexed speakers
* 76 keys and 48-note polyphony
* Individual L/R output
* Assignable real-time control knobs, DSP Effects, and Pitch Bend
* Connectivity with audio and MIDI capabilities
* USB TO DEVICE terminal
* Pattern function to create your own grooves - 25 patterns
* Arpeggio function
* Worldwide sounds support your music
* Yamaha Education Suite (Y.E.S.)
* Music Database

The PSR-EW400 is the top of the line keyboard in the PSR-E Series for both piano focused players and live performers. The 76-key touch response keyboard, various easy-to-use professional features and new Live! Grand Piano voice make this a great instrument for practice, performance and creating. 12W + 12W amplifiers drive on-board sound system, and L/R outputs provide professional connectivity to PA systems or recording hardware.

Specifications:

Colour/Finish: Black
Dimensions (W x H x D): 1,178 mm x 138 mm x 412 mm (46-3/8" x 5-7/16" x 16-1/4")
Weight: 8.4 kg (18 lbs 8 oz.) not including batteries

Control Interface

Number of Keys: 76
Touch Response: Soft, Medium, Hard, Fixed
Pitch Bend: Yes
Control Knobs: Yes
DisplayType: LCD (Liquid Crystal Display)
Language: English
Panel Language: English

Voices

Tone Generating Technology: AWM Stereo Sampling
Number of Polyphony (Max.): 48
Preset Number of Voices: Live! Grand Piano +　236 panel Voices + 24 Drum/SFX kits + 40 Arpeggio + 457 XGlite Voices
Featured Voices: 1 Live! Voice, 8 Sweet! Voices, 3 Cool! Voices, 3 Dynamic Voices
Compatibility: GM and XGlite

Effects

Types
- Reverb: 9 types
- Chorus: 5 types
- DSP: 10 types (assignable on control knobs)
- Master EQ: 6 types
- Harmony: 26 types
Functions
- Dual/Layers
- Split
- Arpeggio: 150 types
- Melody Suppressor
- Crossfade（for Internal/AUX IN）

Accompaniment Styles

Number of Preset Styles: 220
Fingering: Multi finger
Style Control: ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL, TRACK ON/OFF
File Format: Style File Format (SFF)
Music Database: 378
One Touch Setting (OTS): Yes
Expansion Style: 10

Songs

Number of Preset Songs: 30
Recording
Number of Songs: 10
Number of Tracks: 6 (5 Melody + 1 Style/Pattern)
Data Capacity: Approx. 19,000 notes (when only melody tracks are recorded)

Functions

Registration: Number of Buttons: 4 (x 8 banks)
Lesson/Guide: Yamaha Education Suite (Y.E.S.): Lesson 1 3 (Listening, Timing, Waiting), Repeat & Learn, Chord Dictionary
Overall Controls
- Metronome
- Tempo Range: 11 - 280
- Transpose: -12 to 0, 0 to +12
- Tuning: 427.0 - 440.0 - 453.0 Hz (approx. 0.2Hz increments)
- Scale Setting
Miscellaneous: PIANO Button (Portable Grand Button)

Storage and Connectivity

Storage
- Internal Memory: Approx. 1.29 MB
- External Drives: USB flash drive
Connectivity: DC IN: DC IN 12V
- Headphones: x 1
- Sustain Pedal
- AUX IN (Stereo-mini)
- OUTPUTL/L+R, R
- USB TO DEVICE
- USB TO HOST (MIDI/Audio: 44.1 kHz, 16 bit, stereo)

Amplifiers and Speakers

Amplifiers: 12 W + 12 W (When using PA-300C AC adaptor)
Speakers: 12 cm x 2

Power Supply

12V DC power supply or 6 x D batteries
Auto Power Off Function

Accessories

Included Accessories: Music Rest and Song Book (Download from Yamaha website)

Patterns

Number of Preset Patterns: 25
Number of Preset Sections: 5
