1010 Music Synth Box

Description

Synthbox is a 4 note polyphonic synthesizer for your Eurorack system. Connect your favorite MIDI controller or CV Generator to synthbox and start jamming with built in presets. Use the touchscreen to choose and shape the waveforms and to apply the built in sound effects.

Features

- MIDI controllable with support for velocity, pitch bend, and modulation wheel
- CV controllable with pitch, gate, and 3 assignable modulators per voice
- 24 bit DACs and internal processing
- 8 wavetable oscillators
- Supports user wavetables from WAV file
- 4 waveform oscillators
- 2 filters, 2 envelopes, 2 LFOS, and a step sequencer per voice
- Global flanger, distortion, and stereo delay effects
- Semi-modular control
- Stereo or individual voice outputs

Technical Specifications

26 HP
+12V: 350mA
-12V: 0mA
5V: 0mA
