The Pro-Mod Series continues upon Charvel's storied legacy of innovative excellence in high-performance guitar design, offering the latest technology and top-notch features that modern players need. An ideal instrument for dazzling high-speed playing, the Pro-Mod San Dimas Style 1 HH FR E boasts scorching sound, stunning style and grin-inducing playing feel and performance.

Crafted from alder, the San Dimas body is coupled with a bolt-on maple neck featuring a pair of graphite reinforcement rods to resist bending and warping under environmental stresses. The speed neck profile is designed for lightning fast playing and completely unhindered position shifts, while the comfortably rolled fingerboard edges provide the broken-in feel of an instrument with plenty of playing miles on it, and plenty more to go. Perfect for faster tempos, the 12"-16" compound radius ebony fingerboard hosts 22 jumbo frets and white dot inlays. For regularly touring musicians, a heel-mount truss rod adjust thumbwheel is a must, allowing for quick and convenient neck relief tweaks.

High-output Seymour Duncan JB and Seymour Duncan '59™ humbucking pickups are directly mounted to the body, cranking out high octane rock 'n' roll tone with plenty of sweet overtones. The volume control conceals a push/pull coil split to have even more tonal variations on tap while the no-load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound that lets the full natural voice of the guitar shine through. Dive to rumbling depths or add a well-placed rising harmonic without sacrificing your tuning with the Floyd Rose 1000 Series double-locking tremolo bridge system.

Designed with sophisticated style in mind, the Pro-Mod San Dimas Style 1 HH FR E is cloaked in a Gloss Black finish with black hardware.

SERIES: Pro-Mod
BODY MATERIAL: Alder
BODY FINISH: Gloss
NECK: Maple
NECK FINISH: Hand-Rubbed Satin Urethane
FINGERBOARD MATERIAL: Ebony
NUMBER OF FRETS: 22
FRET SIZE: Jumbo
POSITION INLAYS: White Dot
NUT MATERIAL: Floyd Rose® 1000 Series Locking
NUT WIDTH: 1.6875" (42.86 mm)
TUNING MACHINES: Charvel®-Branded Die-Cast
SCALE LENGTH: 25.5" (648 mm)
BRIDGE: Floyd Rose® 1000 Series Double-Locking Tremolo (Recessed)

PICKUPS:
Neck: Seymour Duncan® '59™ SH-1N
Bridge: Seymour Duncan® JB TB-4
PICKUP SWITCHING: 3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Inner Coils, Position 3. Neck Pickup - (Split Engaged) - Position 1. Bridge Outer Coil, Position 2. Both Outer Coils, Position 3. Neck Outer Coil
CONTROLS: Volume (Push/Pull Coil Split), No-Load Tone
CONTROL KNOBS: Knurled Flat-Top
HARDWARE FINISH: Black
STRINGS: Nickel Plated Steel (.009-.042 Gauges)
