Audient - EVO8

Description

Capture your microphones and instruments and start recording audio directly to your computer with EVO 8's intuitive feature set. EVO 8 has all of the innovative new features found on EVO 4 but provides additional inputs and outputs alongside unrivalled performance and functionality all off bus power. Made for the smart creative, EVO 8 will deliver a powerful recording solution no matter your artform.

Key Features
* 4x EVO Preamps - Get the most from your microphones with the warm and accurate EVO preamps offering 58dB of gain range.
* Class Leading AKM Converters (AD/DA) - Hear your recordings more accurately than ever and make better mix decisions with 113dB of dynamic range.
* Smartgain - Dial in your channels automatically
* JFET Instrument Input - Plug your guitar or bass straight in through the JFET instrument input and start recording instantly.
* Smart Touchpoints - Control your speakers, headphones and channels all using the volume encoder
* 2 x Stereo Speaker Outputs - Plug in two sets of speakers
* 2 x Headphone Outputs - High performance headphone outputs
* Low Latency Software Mixer - Designed to simplify and adapt to your workflow
* Audio Loop-back - Audio Loop-back enables you to record your computer audio at the same time as your microphones. Ideal for podcasters and streamers.
* USB2.0 Bus Powered - Power from your computer
* Phantom Power - True switchable +48V over Bus Power
* Free Software + Plugins - All you need to start

Smartgain Mode - Work smarter not harder
Make sure you capture everything perfectly with Smartgain mode. Start playing or singing and Smartgain mode will automatically set the level of your microphones. You can even perfectly match and adjust gain to all channels simultaneously.

Customisable Software Mixer
Designed to simplify and adapt to your workflow, the EVO Mixer enables you to effortlessly set up and route your inputs + outputs, provide ultra-low latency monitoring, balance and set your levels, activate phantom power, set up dedicated artist headphone mixes and more.

Free software
Compatible with all major audio software and plugins, EVO 8 comes bundled with a collection of professional software, giving you everything you need to start recording.

Specifications

Microphone Preamplifier
Mic Gain Range: 58dB
Line Gain Range: 58dB (-10dB pad)
Phantom Power: 48V +/-4V @ 10mA/Channel (only 2 channel available on USB-A host computers
Mic EIN: < -128dBu
CMRR: > 85dB @ 1kHz
Maximum Input Level: +16dBu
Input Impedance (Mic): >3kΩ Balanced
Input Impedance (Line): > 10kΩ Balanced
Frequency Response: +/-0.5dB 10Hz to 40kHz
Crosstalk: < -105dBu @ 1kHz & 10kHz
THD+N @ 0dBu (1kHz): < 0.0015%
SNR: 100dB
XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)

ADC Inputs
Digital Reference Level: 0dBFS = +8dBu
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -105dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz): < 0.001%
Dynamic Range: 113dB A-weighted

DAC Outputs
Maximum Output Level: +11dBu
Digital Reference Level: 0dBFS = +11dBu
Output Impedance: < 100Ω Balanced
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: < -110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): < 0.0015%
Dynamic Range: 113dB A-weighted

Headphone Output
Output Impedance: < 50Ω
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): < 0.0015%
Dynamic Range: 113dB A-weighted

USB 2.0 High Speed
No. Of Input Channels: 24 Analogue
No. Of Output Channels: 4 Digital
Connector: USB Type-C
Included Cables: 1m USB 2.0 Type-C to USB Type-C

Weight & Dimensions
Weights: 0.475kg
Dimensions: 190mm (w) x 70mm (h) x 70mm (d)
