DPA Microphones - 4099-DC1-201B

Description

Small-diaphragm Supercardioid Condenser Microphone with clip cable for acoustic upright bass.

The 4099 is already the recognized standard for this type of microphone and the CORE version adds just another layer of sound quality that further distances this mic from its competitors. The award-winning 4099 Series brings more clarity and details to your music, across the entire dynamic range. This condenser microphone rejects unwanted noise and accurately captures the true voice of your acoustic instrument. Anyone looking for the very highest sound quality should choose CORE.

The 4099 CORE for Loud SPL is the perfect mic solution for PA amplification and live recording of acoustic upright bass. It offers a sound that is considerably more natural than an internal microphone or pickup. There are several excellent placement possibilities on the instrument.

The microphone and its mounting system are both designed and optimized for the double bass. This ensures that the best mounting and audio reinforcement is achieved when performing live. The mic clip attaches to the E- and G-string below the bridge. This ensures mic placement in the sweet spot between the bridge and fingerboard.

Features
* CORE by DPA technology inside
* Supercardioid condenser microphone
* Handles high SPLs
* Superior gain before feedback
* Flexible and easy mounting
* Gentle and easy to mount on the instrument
* Detachable cable and a versatile gooseneck extender

Specifications
Directional pattern: Supercardioid
Principle of operation: Pressure gradient
Cartridge type: Pre-polarized condenser
Frequency range: 20 Hz - 20 kHz
Frequency range, 2 dB, 20 cm (7.9 in): 80 Hz - 15 kHz with 2 dB soft boost at 10-12 kHz
Sensitivity, nominal, 3 dB at 1 kHz: 6 mV/Pa; -44 dB re. 1 V/Pa
Equivalent noise level, A-weighted: Typ. 23 dB(A) re. 20 Pa (max. 26 dB(A))
S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL): Typ. 71 dB(A)
Total harmonic distortion (THD): < 1% up to 123 dB SPL peak
Dynamic range: Typ. 100 dB
Max. SPL, peak before clipping: 142 dB
Output impedance: From MicroDot: 30 - 40 Ω. From DAD4099/DAD6001-BC: 100 Ω
Cable drive capability: Up to 300 m (984 ft) with DAD4099 or DAD6001-BC XLR Adapter
Output balance principle: Signal balanced with DAD4099 or DAD6001-BC XLR Adapter
Common mode rejection ratio (CMRR): > 60 dB from 50 Hz to 15 kHz with DAD4099 or DAD6001-BC XLR Adapter
Power supply (for full performance): Min. 5 V to max. 50 V through DPA adapter for wireless systems
Current consumption: Typ. 1.5 mA (microphone). 3.5 mA with DAD4099 or DAD6001-BC XLR Adapter
Connector: MicroDot
Color: Black
Weight: 46 g (1.62 oz)
Microphone diameter: 5.4 mm (0.21 in)
Microphone length: 45 mm (1.8 in)
Cable length: 1.8 m (5.9 ft)
Cable diameter: 1.6 mm (0.06 in) / 2.2 mm (0.09 in)
Polarity: +V at MicroDot pin for positive sound pressure (and pin 2 on DAD4099 or DAD6001-BC XLR adapter)
Temperature range: -40C to 45C (-40F to 113F)
Relative humidity (RH): Up to 90%
Gooseneck length: 140 mm (5.5 in)
